    SAE J517 100 R2 AT High Pressure Hydraulic Hose 3/8 1/2 for Tractor Trolley


    SAE J517 100R2 AT High Pressure Hydraulic Hose 3/8 , 1/2" for Tractor Trolley


    Description:


    Standard: SAE J517


    Construction

    Tube: NBR synthetic rubber.
    Reinforcement: Two high-tensile steel wire braided.
    Cover: NBR oil and weather resistant synthetic rubber.


    Temperature: -40℃ - +100℃


    Color: Black, Grey, Blue, etc.


    Standard length: 100m/roll


    Fitting: 00210 or 03310 ferrule and 1 serious crimping fitting.


    Specification of R2.pdf


    Specifications:


    Double Wire Braided Reinforced Hydraulic Rubber Hose


    Item CodeInner DiameterOuter DiameterWorking PressureBurst PressureLengthMeasurementWeight
    inchmmmmbarpsibarpsimcbm/rollkg/m
    R2-053/164.812.341460001655240001000.32
    R2-061/46.415.540058001600232001000.05140.37
    R2-085/168.016.535050751400203001000.06120.412
    R2-103/89.519.233047851320191401000.07840.53
    R2-131/212.721.827539881100159501000.08330.64
    R2-165/816.025.52503630100114520500.0740.77
    R2-193/419.029.5215312086012480500.08330.96
    R2-25125.438.116524006629600500.14451.35
    R2-321 1/432.048.012518205027280200.2092.05
    R2-381 1/238.055.09013103615240200.25092.511
    R2-51250.868.68011603204640200.3796

    3.165



    Application:

    This high pressure hydraulic hose SAE J517 100 R2 AT 3/8" and 1/2" can be used for tractor trolly




    Competitive Advantage:

    It is made according to SAE J517 / DIN EN 853 standard.


    We have several ways of hydraulic hose packaging for our customers:

    1. Colorful poly stripes (normal packing)
    2. reel
    3. customized carton hose assembly
    4. customzied PE bag for hose assembly

    We supply OEM, ODM according to customer’s requirement.


    The hydraulic hoses and fittings can be assembled in our factory.


    The hydraulic hoses R1 and R2 can be made in smooth surface.


    We also supply hose protector for our customers.
