    Wear - Resisting High Pressure Hose with Fittings For Automobiles Industry

    Ask Lasest Price
    Brand Name : PASSION
    Model Number : imported PTFE Hose, SAE 100R14
    Certification : ISO 9001-2008, CE
    Price : Negotiable
    Payment Terms : L/C, , T/T, Western Union, MoneyGram
    Supply Ability : 300000M/Month
    Delivery Time : within 25days after we have received the advanced payment.
    • Product Details
    • Company Profile

    Wear - Resisting High Pressure Hose with Fittings For Automobiles Industry

    Wear - Resisting High Pressure Hose with Fittings For Automobiles Industry


    Tube: Temperature chemical resistant PTFE material.

    Cover: Braided with Stainless Steel (Diameter 0.2mm for 1/8'' Hose, Diameter 0.25mm for 5/16’’-1’’ Hose).

    Temperature:-50C up to +220C.

    Application: Used on Mechanical hydraulic system in Shipping Industry, Auto Industry and Ocean Industry.

    Fitting Type: 1/4’’ NPT Female/Male;28 degree Banjo Fittings.


    SERIAL

    I.D(inch)

    I.D*O.D(mm)

    W.P (bar)

    B.P (bar)

    Length/roll(m)

    PPT-04

    1/4"

    6.0*8.7

    179.5

    718

    >50

    PPT-04

    6.5*9.2

    170.0

    680

    >50

    PPT-05

    5/16''

    8.0*10.8

    155.0

    620

    >50

    PPT-06

    3/8"

    10*12.4

    135.0

    540

    >50

    PPT-08

    1/2"

    12.7*15.9

    90.0

    360

    >50

    PPT-10

    5/8"

    15.9*19.3

    62.5

    250

    >40

    PPT-12

    3/4"

    19.0*22.3

    55.8

    223

    >30

    PPT-14

    7/8''

    22.2*25.8

    52.5

    210

    >20

    PPT-16

    1"

    25.0*29.5

    48.8

    195

    >10


    Specifications


    Material

    Temperature chemical resistant PTFE material. +304 Stainless Steel Braided

    Temperature

    -50C-260C

    I.D(inch)

    1/8’’-1’’

    I.D 1/8inch

    Specially used as brake hose.

    I.D*O.D(mm)

    6.0*8.7-25.0*29.5

    W.P

    179.5BAR-48.8BAR

    B.P

    718BAR-195BAR

    Length/roll(m)

    >50

    Application

    Used on Mechanical hydraulic system in Shipping Industry, Auto Industry and Ocean Industry.

    Type

    Smooth Surface and Corrguated Surface

    Type

    Imported PTFE Material and Made in China PTFE Material.


    *The Inner Diameter and Outer Diameter only refer to the PTFE Hose inside.

    When you measure please don’t include the Stainless Steel.


    *The Hose is tested when the Hose is under condition of rest.

    *Temperature-Pressure:

    20C---------P

    100C-------0.43P

    150C----------0.3P

    200C------------0.22P

    220C--------------0.2P




    For more detailed information, please contact us.
