    90 Degree BSP Hydraulic Hose Fitting 60 Degree Cone Seal ( 22691 )

    Ask Lasest Price
    Brand Name : PASSION
    Model Number : BSP FEMALE 22691
    Certification : ISO 9001-2008, CE
    Price : Negotiated
    Payment Terms : T/T, L/C, Western Union, Paypal, MoneyGram
    Supply Ability : 60,000 pcs per month
    Delivery Time : Within 20 to 30 days after we receive advance payment
    • Product Details
    • Company Profile

    90 Degree BSP Hydraulic Hose Fitting 60 Degree Cone Seal ( 22691 )


    90 Degree BSP Hydraulic Hose Fitting 60 Degree Cone Seal 22691


    Descrioption:


    It is hydraulic hose fitting 90 degree BSP Female 60 degree Cone Seal, English style one. Almost all of our customers need this kind of hydraulic fitting.


    Applications:

    Hydraulic Hose Fitting is widely used in the hydraulic and fluid conveying system of machinery,

    oilfield, mine, building, transportation and other industries.


    Specifications:


    90 DEGREE BSP FEMALE 60 DEGREE CONE


    22691 22691-T 22691-W


    Part No.Thread EHose BoreDimensions
    DNDASHACHS2
    22691-02-03G1/8"X2850326.55.531.514
    22691-02-04G1/8"X28604305.534.514
    22691-04-03G1/4"x1950326.55.533.519
    22691-04-04G1/4"x19604305.536.519
    22691-04-05G1/4"x19805335.539.519
    22691-04-06G1/4"x191006305.536.519
    22691-06-04G3/8"x19604306.337.722
    22691-06-05G3/8"x19805336.340.722
    22691-06-06G3/8"x19100635.36.34322
    22691-08-06TG1/2"x14100635.3743.327
    22691-08-08G1/2"x141208417.55127
    22691-08-10G1/2"x14161056.57.555.527
    22691-10-08G5/8"x141208419.551.530
    22691-10-10G5/8"x141610569.55630
    22691-12-08TG3/4"x1412084110.952.132
    22691-12-10G3/4"x14161056.510.956.632
    22691-12-12G3/4"x14201264.910.966.132
    22691-16-12TG1"x11201265.511.768.341
    22691-16-14G1"x11221471.211.769.341
    22691-16-16G1"x11251678.711.773.841
    22691-20-16TG1.1/4"x112516781169.550
    22691-20-20WG1.1/4"x11322091.51184.350
    22691-24-24WG1.1/2"x114024109.41310355
    22691-32-32WG2"x115032131.816123.370

    Note: 1 for use with braided hoses, textile hoses and thermoplastic hoses, if use with spiral hoses, hose fitting series number is 22692-**-**.

    It is hydraulic hose fittings 90 degree BSP Female 60 degree Cone Seal in silver color (22691).

    It is hydraulic hose with fitting 22611 and 22691. We can do it in our factory.



    It is our warehouse.




    Competitive Advantage:

    -Our factory owns a group of high quality and high-tech professional designers and personnel group. It
    possesses a series of the fully automatic computer CNC machine tools and high precision lathes, the
    multiple spindles too machines, hexangular tool machines and electric heated bent pipe machines. We
    have strictly adopted the professional personnel to carry on the tests and examinations for our products

    in order to provide an assurance in the high-quality for all the customers.


    -Our factory success fully obtained the international quality certification system: ISO9001:2000 and

    domestic production permit of hydraulic hose fittings.


    -Our hydraulic hose fittings have been exported to many countries and areas in Europe, America, the

    Middle East, the Southeast Asia and the South America.


    -The material of our hydraulic hose fittings is good quality carton steel #45.


    -Our warehouse is on the second floor, it is better to keep dry of stock of fittings.


    -Our hydraulic hose fittings are well packed in cartons and wooden boxes. It is better to avoid fitting

    damping.


    -The branding can be printed on the fittings.


    -The fittings can be customized according to samples or drawings.


    - We have crimping machine to crimp hydraulic hose assembly.


    - We use new technic to galvanize zinc. It makes carbon steel fitting looks like stainless steel one. The appearance is fantastic.
